This 36" x 9" commemorative poster celebrates the record-setting R/C jump seen in the Dude Perfect R/C Edition video and is only available from Traxxas.com, while supplies last.
Enter the coupon code "WORLDRECORD" to get the LIMITED EDITION POSTER with orders of $25 or more on traxxas.com!*
Check out the complete build sheet below and build your own record-breaking E-Revo!
| Vehicle: | Traxxas E-Revo Brushless Edition (#56087-3) | |
|---|---|---|
| ESC: | MXL-6s Waterproof | |
| Motor: | Brushless, 2200kV | |
| Power System: | Traxxas Power Cell 6S LiPo (#2872X) | |
| Gearing: | XO-1 29-T pinion (#6492), 36-T spur (#3953) | |
| Tire/Wheel: | XO-1 (#6477) | |
| Chassis Brace: | Rear Brace (#5632) | |
| Wing / Wing Mount: | Removed | |
| Suspension: | Front | Rear |
| Spring: | Black Rate (#5441) | Gold Rate (#5439) |
| Shock Valving: | Piston 1 (#5461) | Piston 2 (#5461) |
| Shock Oil: | 80 wt | 80 wt |
| Toe Angle: | 1.0° out | 2.0° in |
| Rockers: | Progressive-2 (P2) | Progressive-2 (P2) |
| Roll Center: | Upper | Upper |
| Camber: | 0° | -1.0° |
| Caster: | 2 clips front and back | N/A |
| Pushrod Location: | Outer | Outer |
| Ride Height: | Shafts Level | Shafts Level |
| Bump Steer: | Mid | N/A |
| Notes: | Truck was setup for high speeds, stability and control. For gearing we used the XO-1 29-T pinion gear (#6492) and the 36-T spur gear (#3953). For extra durability, we added our rear Traxxas chassis brace (#5632). Surface was smooth concrete with medium traction. The wing and wing mount were removed to reduce rear downforce. Add hook and loop to secure body to battery doors. |
|---|
